BQX-GK-C400 Vehicular Mobile Signal Management System

BQX-GK-C400 Vehicular Mobile Signal Management System Product Introduction The BQX-GK-C400 is an advanced digital Signal Management Equipment designed for comprehensive mobile communications contro……

Send Inquiry

Functional characteristics

BQX-GK-C400 Vehicular Mobile Signal Management System

Product Introduction

The BQX-GK-C400 is an advanced digital Signal Management Equipment designed for comprehensive mobile communications control. This vehicular IMSI Catcher provides sophisticated Signal Acquisition across 2G-5G networks. Functioning as a mobile Communications Base Station, it enables precise Mobile Signal Interception and terminal management. As a critical Electronic Perimeter Surveillance solution, its intelligent whitelist/blacklist capabilities ensure secure environments while maintaining normal communication for authorized users.

Core Capabilities

Multi-Network Coverage

Comprehensive 2G/3G/4G/5G support across FDD/TDD modes for effective Signal Management

Large-Scale Area Control

400m operational radius covering 500,000m² area (RSSI≤-75dBm) for perimeter surveillance

Intelligent Automation

Auto-scanning of available bands with instant public parameter configuration (Base Station Information Collector)

Access Control

Whitelist/blacklist management ensuring authorized communications blocking unauthorized devices

Real-Time Multi-Targeting

Simultaneous monitoring and second-level switching for multiple target tracking (Signal Monitoring)

Flexible Power Options

AC220V or portable battery operation for mobile deployment versatility (Emergency Communications System)

Technical Specifications

Parameter	Specification
Supported Frequency Bands	4G: B1/3/5/8/34/38/39/40/41 5G: N1/3/5/8/28/41/78/79
Carrier Capacity	12 simultaneous carriers (6x5G+6x4G or 4x5G+8x4G)
Output Power	≥46dB dynamic adjustment (5G/4G)
Scanning & Configuration	Automatically scans public networks and configures parameters; manual adjustments without rebooting
Access Control List	≥10 simultaneous blacklisted terminals; whitelist allows authorized communication
Target Identification	Multi-operator IMSI capture (Mobile/Unicom/Telecom/Broadcast)
Countermeasure Capability	Multi-operator 4G/5G signal suppression
Multi-Target Tracking	Simultaneous targeting with second-level response
Value Reporting	0-99 range with ≥98% reporting effectiveness
Power Supply	AC220V or portable battery box (convertible to DC-48V)

Operational Applications

This Signal Management Equipment delivers critical security for confidential facilities and sensitive environments. As a vehicular Electronic Perimeter Surveillance solution, it effectively detects unauthorized devices in restricted areas like classified installations and secure meetings. The system’s Cell Phone Detection capabilities enable detection of off-record devices while its whitelist functionality maintains normal communications for authorized personnel. Particularly valuable for law enforcement operations requiring mobile Signal Monitoring capabilities in dynamic scenarios.
