BQX-GK-B500 Portable Mobile Phone Code Detection & Positioning Equipment

Home > Product > mobile device control series > BQX-GK-B500 Portable Mobile Phone Code Detection & Positioning Equipment

mobile device control series

BQX-GK-B500 Portable Mobile Phone Code Detection & Positioning Equipment

.header { text-align: center; margin-bottom: 30px; padding-bottom: 20px; border-bottom: 3px solid #2c6ab0; } .header h1 { ……

Send Inquiry

Functional characteristics

Product Introduction

The BQX-GK-B500 portable mobile phone detection and positioning equipment is a specialized device designed to meet customer requirements. Utilizing dedicated physical layer and protocol stack technologies with professional handheld terminal control, it analyzes and identifies mobile terminals. Supporting current LTE and NR network bands, it’s widely applicable for security and confidential environments in public security, state security, military, and other high-security settings.

Core Features

Comprehensive System Coverage

Supports dual-channel operation for both 4G and 5G networks, covering all frequency bands to ensure comprehensive surveillance and compatibility with the latest mobile network technologies.

Code Detection & Collection

Captures IMSI of LTE and 5GNR mobile terminals within coverage area. Performs statistical analysis of target IMSI based on multiple capture results for accurate identification.

Extensive Search Range

Reaches up to 500 meters in open areas and covers 10-20 floors in high-rise buildings. Actual coverage varies based on public network environment conditions.

Multi-Carrier Concurrency

Supports up to 14 concurrent carriers (non-round robin) with 5G and 4G carrier splitting capability for efficient multi-channel monitoring.

Automatic Public Network Configuration

Equipped with full-network engineering model capabilities that automatically acquire and configure optimal public network parameters to maximize operational efficiency.

Rapid Apple Device Detection

Quickly identifies Apple iOS devices with prominent visual indicators (control function support only).

High-Performance Stability

Supports whitelist import of ≥100,000 entries and simultaneous target search for ≥200 devices (control functions only), ensuring robust performance in demanding environments.

Performance Specifications

Parameter	Specification
Dimensions (L×W×H)	283 × 290 × 93 mm
Weight	Approx. 5.5 kg
Operation Mode	NR, LTE
Frequency Bands	LTE: B1, B3, B5, B8, B34, B39, B40, B41 NR: N1, N28, N41, N78, N79
Carrier Capacity	Max 14 concurrent carriers (non-round robin, supports 5G/4G carrier splitting)
Operation Modes	Sweeping, Code Detection, Positioning, Control
Synchronization Methods	GPS, BeiDou, Air Interface
Receiver Sensitivity	-103 dBm
Output Power	MAX 4W (software adjustable, 1dB step)
Antenna Gain	Approx. 10 dBi
Battery	Removable, ≤1.5 hours per battery, includes two batteries
Operating Environment	-20°C to 50°C
Operation Platform	Android Mobile OS

Application Scenarios

The BQX-GK-B500 is suitable for various security-sensitive environments where effective monitoring and control of unauthorized mobile devices are required:

Public Security & Protection: Crowd monitoring during public events and critical infrastructure security
Sensitive Facilities Protection: Government buildings, research centers, and strategic installations
Prison Supervision: Preventing unauthorized communication within correctional facilities
Conference & Event Security: Ensuring confidential meetings remain secure from electronic eavesdropping
Corporate Campus Security: Protecting intellectual property and sensitive business operations
Campus Safety: Educational institution security management
Temporary Control Zones: Emergency response situations requiring mobile device detection

The equipment enables effective monitoring and control of unauthorized mobile phone usage, ensuring information security and preventing illegal communication activities in these critical environments.
